Melt Blown Polypropylene Filter Cartridge ,Melt Spinning Water
Melt Blown Polypropylene microfiber is adopted in the product, which is wound and thermally pressed according to certain aperture and gradient through special process.
Features:
● 100% high purity polypropylene (melt blown), no adhesives
● High dirt holding capacity and low pressure loss
● Many connections(DOE,226,222 End caps) are available
● Wide chemical compatibility , various micron ratings(1um to 100um)
● One piece construction, up to 1524mm(60”)
Typical applications:
● Prefiltration in process water treatment industry
● Clarifiction for waste water treatment
● Bottled water, wine, beer pre-filtration in food&beverage industry
● Prefiltration before RO system in electronics process water
● Organic solvents, inks, plating solution, metal cutting, fluids, photoresist filtration
Specifications:
| Materials of Construction | Filter Media | Melt Blown Polypropylene |
| Micron Rating | 1.0,5.0, 10.0, 20, 50, 70, 100um |
| Inner Core | Polypropylene Coreless |
| O-rings /Gaskets(only for 226,222, Ends) | Silicone, Nitrile, EPDM, Viton |
| Filtration Efficiency | ≥80% |
| Cartridge Dimensions | Outer Diameter | 63mm(2.5”)/113mm(4.5”) |
| Inner Diameter | 28mm(1.10”) |
| Length (based on Cut Ends) | 10”,20”,30”,40”,50”,60” |
| Filtration Area(m2) | 0.4 m2 per 10” |
| Operating Conditions | Normal Operating Temperature | Up to 50℃ (122℉) |
| Max. Operating Temperature | 80℃(176℉) at △P≤1.0bar(14.5psi) |
| Normal Flow direction | 4.0bar(58psi) at 25℃(77℉) |
| Reverse Flow direction | 2.0bar(29psi)at 25℃(77℉) |
| PH Value Compatibility | 1-13 |
| Sterilization | Not recommended |
FAQ:
Q: Are you trading company or manufacturer ?
A: Yes, we are the manufacturer with continuous and improved R & D, production, sales and service supply.
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge if the value is not big, but the courier charge will be on your side.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shipment. ( Mainly accept Paypal, West Union and T/T)
Shanghai Daitto Filtration now has quite a few products in stock in its factory. Also dealing with customized service, we warmly welcome you to buy or wholesale discount and cheap products at low price with us.
